The Fluke 1630-2 FC Stakeless Earth Ground Clamp is the kind of high-quality, rugged tool you expect from Fluke. Heavy-duty clamp jaw stays in alignment and in calibration even in every day, on-the-job industrial environments. Test the grounding components of equipment in hard-to-reach spaces, including areas that are indoors or fully paved and do not permit driving auxiliary test stakes. Stay on line—identify ground loop resistance without the need to disconnect then reconnect the earth electrode from the system.

Stakeless earth ground measurement testing
• You can also perform earth ground tests in places you’ve not considered before: inside buildings, power pylons, or anywhere you don’t have access to soil
• The Fluke 1625-2 earth ground tester can measure earth ground loop resistances using only clamps
• With this test method, two clamps are placed around the earth ground rod and each are connected to the tester
The Fluke 1625-2 improves your earth ground testing process with:
• Automatic Frequency Control (AFC) - identifies existing interference and chooses a measurement frequency to minimize its effect, providing more accurate earth ground value
• R* measurement - calculates earth ground impedance at 55 Hz to more accurately reflect the earth ground resistance that a fault-to earth ground would see
• Adjustable limits - for quicker testing
The Fluke 1625-2 gives you versatility in earth ground testing[b]
• 3- and 4-pole fall-of-potential, earth resistance loop testing
• 4-pole soil resistivity testing
• Selective earth ground rod testing using 1 clamp
• Stakeless earth ground rod testing using 2 clamps

[b]The Fluke 1625-2 offers you simpler, faster earth ground tests than ever before
• The 1625-2 offers internal memory storage up to 1500 records
• Accessible via USB port for rapid data transfer and viewing of results
• This earth ground tester also gives you world-class accessories that take the tedium out of earth ground testing

Additional tool features
• Heavy duty stakes can be hammered into dry, hard soil.
• And new color-coded wires make setup simple and help eliminate mistakes and speed up setup and tear down time as much as 50%
• IP56 rated for outdoor use
• Rugged carrying case

Key Features
The Fluke 1625-2 is a unique earth ground tester that can perform all four types of earth ground measurement:
• 3- and 4-Pole Fall-of-Potential (using stakes)
• 4-Pole Soil Resistivity testing (using stakes)
• Selective testing (using 1 clamp and stakes)
• Stakeless testing (using 2 clamps only) Adjustable limits - for quicker testing
• IP56 rated for outdoor use
• Rugged carrying case

• 3 phase indication
• Indication of phase rotation
• Clear LCD display
• No battery required

• Non-contact voltage detection from 90 to 1000 V AC
• Innovative 'Battery Check' ensures battery is in good condition*
• Integrated clip design, optimized for pocket storage

Test the safety and performance of a type 1, level 1 or level 2 electric vehicle ac charging stations (EVSEs) with the Fluke FEV100. This test adapter simulates the presence of an electrical vehicle, allowing you to conduct tests in combination with appropriate test instruments such as a digital multimeter or oscilloscope. Use the FEV100 to verify an EVSE is working properly after install and during periodic maintenance, or troubleshoot an EVSE if it is not delivering the appropriate charge.
Electrical safety
EVSE charging cables may become damaged over the course of use, increasing electric shock risks to users. Stay protected from and check risk of electric shock with the GFCI trip test. This function verifies the breaker of the EVSE is connected by detecting ground faults. Additionally, the PE grounding protection pre-test verifies that there is no presence of dangerous voltage at the ground terminal.
Simplicity and convenience
Perform a variety of tests including ground fault checks, insulation of wires, measuring voltage and duty cycle to see max current available for charging all in one adapter that safely integrates with the Fluke portfolio of test and measurement tools. There is no need to bring an electric vehicle onsite for EVSE troubleshooting: the adapter acts as an electric vehicle when connected to an EVSE for easy performance and maintenance testing.
Recommended tools for use with the FEV100

Key features
• Check protective earth for correct wiring and functioning with the PE pre-test feature.
• Perform GFCI troubleshooting of EVSE and verify operation within safety standards.
• Test charging states of EVSE with CP state simulation.
• Verify charging voltage and maximum available current using a multimeter.
• SAE J1772 compliant to North American standards.
