Test the safety and performance of a type 1, level 1 or level 2 electric vehicle ac charging stations (EVSEs) with the Fluke FEV100. This test adapter simulates the presence of an electrical vehicle, allowing you to conduct tests in combination with appropriate test instruments such as a digital multimeter or oscilloscope. Use the FEV100 to verify an EVSE is working properly after install and during periodic maintenance, or troubleshoot an EVSE if it is not delivering the appropriate charge.
Electrical safety
EVSE charging cables may become damaged over the course of use, increasing electric shock risks to users. Stay protected from and check risk of electric shock with the GFCI trip test. This function verifies the breaker of the EVSE is connected by detecting ground faults. Additionally, the PE grounding protection pre-test verifies that there is no presence of dangerous voltage at the ground terminal.
Simplicity and convenience
Perform a variety of tests including ground fault checks, insulation of wires, measuring voltage and duty cycle to see max current available for charging all in one adapter that safely integrates with the Fluke portfolio of test and measurement tools. There is no need to bring an electric vehicle onsite for EVSE troubleshooting: the adapter acts as an electric vehicle when connected to an EVSE for easy performance and maintenance testing.
Recommended tools for use with the FEV100

Key features
• Check protective earth for correct wiring and functioning with the PE pre-test feature.
• Perform GFCI troubleshooting of EVSE and verify operation within safety standards.
• Test charging states of EVSE with CP state simulation.
• Verify charging voltage and maximum available current using a multimeter.
• SAE J1772 compliant to North American standards.

• OpenJaw™ design: measure current without breaking the circuit
• Tester automatically selects AC or DC voltage, up to 1000 V
• Work in tight spaces with detachable Slim Reach probe tips

The Fluke 1507 is a versatile, compact, handheld insulation tester for advanced industrial and electrical insulation testing. Its multiple test voltages make it the ideal tool for many troubleshooting, commissioning, and preventative maintenance applications.
Take advantage of the 1507 full feature set to easily and quickly perform advanced insulation resistance testing. Its handy size and light weight make it easy to pack and use. Additional features, like the remote probe, save both time and money especially when performing repetitive tests. And its reasonable price and rugged reliability make it an excellent value.
Other useful capabilities:
• Performs insulation tests from 0.01 MΩ to 10 GΩ
• Includes live circuit detection to prevent insulation test if voltage >30 V is detected
• Includes auto-discharge of capacitive voltage for added user protection
• Measures AC/DC voltage from 0.1 V to 600 V and resistance from 0.01 Ω to 20.00 kΩ
• Provides lo-ohms earth-bond continuity (200 mA)
• Simplifies repetitive or hard-to-reach testing with the remote test probe
• Saves battery power with auto power off
• Presents results on a large, backlit display
• Features CAT IV 600 V overvoltage category rating
• Comes with remote probe, test leads, test probes, alligator clips and one-year warranty
• Accepts optional Fluke TPAK magnetic hanging system to free your hands for other work
• Runs on four AA alkaline batteries (NEDA 15 A or IEC LR6) for at least 1000 insulation tests

Key Features
• Rugged, compact advanced insulation resistance tester for electrical contractors and industrial and commercial electricians
• Automatically calculates Polarization Index and Dielectric Absorption Ratio
• Makes repetitive tests simple and easy with a Compare (Pass/Fail) function
• Offers multiple insulation test voltages: 50 V, 100 V, 250 V, 500 V, and 1000 V

Fluke 1662 menawarkan keandalan Fluke, pengoperasian yang mudah, dan semua kemampuan pengujian yang diperlukan untuk pengujian instalasi sehari-hari.

Fitur utama
Fluke 1662 memberi lebih banyak daya di tangan Anda dengan menguji semua pengaturan lokal secara cepat dan efisien.
Fungsi pengukuran
• Fungsi pengukuran
• Tegangan & frekuensi
• Pemeriksa polaritas perkabelan, mendeteksi kerusakan kabel N
• Resistansi insulasi
• Kontinuitas & resistansi
• Pengukuran kumparan motor dengan pengujian kontinuitas
• Resistansi loop & line
• Prospective earth fault current (PEFC/IK)
• Prospective short-circuit current (PSC/IK)
• Waktu switching RCD
• Tingkat tripping RCD (pengujian ramp)
• Mengukur waktu trip & arus untuk RCD tipe A & AC dalam satu pengujian
• Arus variabel RCD
• Urutan pengujian RCD otomatis
• Indikator urutan fase
Fitur lainnya
• Auto Start otomatis yang dapat diaktifkan/dinonaktifkan untuk pengujian RCD & Loop
• Pengujian mandiri
• Tampilan yang terang
• Waktu dan tanggal (jika digunakan dengan perangkat lunak opsional FlukeView)
Aksesori yang disertakan
• Satu kabel jalur input tugas berat
• Hard case
• Probe remote control
• Zero adapter
